Sacrificial anode series
Home > Products > Sacrificial anode series
Main purpose：Zinc anode is widely used in petroleum, chemical, Marine engineering, transportation, electricity, municipal engineering and other fields, is typically used for resistivity is lower than 2000 Ω. Cm medium; If the protection of steel structure has good coating or under the condition of soil moisture, zinc anode can be used to bring over 2000 Ω. Cm medium. In order to improve the use of zinc strip anode performance, filling material can be used, the standard of filling material is calcium sulfate added bentonite, to absorb and retain water, reduce the resistance.
Execution standard： ASTM B 843-1995 SY/T0019-1997
Chemical composition
kind | Al | Cd | Fe(Max) | Pb(Max) | Cu(Max) | Zn |
| I | 0.1-0.5 | 0.02-0.07 | 0.005 | 0.006 | 0.005 | allowance |
| II | 0.005（Max） | 0.003(Max) | 0.0014 | 0.003 | 0.002 | allowance |
High purity zinc | 0.003(Max) | 0.002(Max) | 0.001 | 0.003 | 0.001 | allowance |
specifications
| model | size（mm） | Single heavy（g/cm） | ||
| A(mm) | B(mm) | C(mm) | ||
| 特大（A） | 25.4 | 31.75 | 30.5 | 35.72 |
| 大（B） | 15.88 | 22.23 | 61 | 17.82 |
| 標(biāo)準(zhǔn)（C） | 12.7 | 14.28 | 152 | 8.93 |
| 小（D） | 8.73 | 11.91 | 305 | 3.72 |
